FF-3DP-ABS1.75-02-Y

ABS Yellow, 1.75 mm, 0.6 kg

  • VERSATILE & EASY TO USE
  • Acrylonitrile butadiene styrene (ABS) is a common thermoplastic strong and durable plastic available in a range of colors.
  • ABS is the plastic used in lots of things around us and is perfect for heated plastic extrusion 3D printing.

▲
  • FF-3DP-ABS1.75-02-Y
  • FF-3DP-ABS1.75-02-Y
  • FF-3DP-ABS1.75-02-Y
  • FF-3DP-ABS1.75-02-Y
  • FF-3DP-ABS1.75-02-Y
▼
Thumbelina Zoom Image

  • ABS filament with 1.75 mm diameter
  • Excellent chemical resistance
  • High Stiffness and good impact resistance at low temperatures
  • Easily processed with good surface finish
  • Can be used in a variety of 3D printers
  • 0.6 kg spool
Specifications
Material: ABS, 1.75 mm diameter
Weight: 0.6 kg/spool
Density at 215°C: 1.05 g/cm3
Melt Flow Index at g/10min, 220°C/ 5kg: 1.8
Melt Point: 210 - 250 °C
Heat-Deflection-Temperature at 0.455 MPa: 85 - 100 °C
Yield Strength at 5mm/min: 45 MPa
Impact Strength: 18 KJ/m2
Ensile Break: 25 %
Diameter: 1.75 ± 0.05 mm
Spool dimensions: 160mm diameter x 53mm height x 32mm central hole

System requirements
A 3D printer with 1.75 mm extruder of temperature around 230 °C, suitable for ABS filament

Packing Details
Q'ty in crtn, pcs12
Crtn volume, CUM0.031968
Crtn weight, kgs10.26
Individual package size LxWxH:175x175x70 mm
Carton size LxWxH:360x370x240 mm
Country of originCN
Barcode8716309091626
Customs code3916909000
Packaging1 Rol/ds

Trade Mark

Product information sheet
